| Motor |
Bosch Performance Line CX (Smart System Gen 5), 85 NM (100-120 NM update via Flow App) |
| Battery Options |
Bosch PowerTube Li-Ion (600 Wh) / (800 Wh) |
| Display & Remote |
Bosch Mini Remote + System Controller |
| Frame |
7005 hydroformed aluminium, 165 mm F.O.L.D. kinematics, 148x12 mm thru axle, Post Mount 180 mm |
| Frame Special Features |
Geometry adjustment of head angle and chainstay length, Tool bag included (excluding size S), Hidden AirTag or Chipolo holder |
| Fork |
Fox 38 Rhythm, Grip 3-Position, 170 mm travel |
| Shock |
Fox DHX Performance Coil, 165 mm travel (Coil rates vary by size: 350/400/500/600 lbs) |
| Brakes (Front | Rear) |
Shimano Deore BR-M6120, 4-piston |
| Disc Brake Rotors |
Shimano SM-RT66, 220 mm (Front) / 220 mm (Rear) |
| Rear Derailleur |
Shimano Deore, 12-speed |
| Shifter |
Shimano Deore |
| Cassette |
Shimano CS-M6100, 10-51T |
| Chain |
Shimano CN-M6100 |
| Crankset |
Samox, 165 mm |
| Chainring |
Samox, 36 T |
| Handlebar |
Alloy, 800 mm width, 30 mm rise |
| Grips |
VP Lock-On Grips |
| Stem |
FOCUS C.I.S. 2.0, 40 mm |
| Headset |
ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated angle headset |
| Saddle |
Focus |
| Seatpost |
Post Moderne DP-212 Dropper (Travel: 125/170/200/200 mm by size), 34.9 mm |
| Wheelset Rims (Front | Rear) |
WTB STi30 TGH, alloy, Mullet (Front: 29" / Rear: 27.5") |
| Hubs (Front | Rear) |
Formula DC-611 | Formula DC-648 |
| Tyres (Front | Rear) |
Maxxis Assegai, DoubleDown, 3C MaxxGrip, 29 x 2.5" | Maxxis Minion DHR II, Downhill, 3C MaxxGrip, 27.5 x 2.5" |
| Weight (600 Wh) |
26.5 kg (in size M, without pedals) |
| Permissible System Weight |
150 kg |
