| Motor |
Bosch Performance Line CX (Smart System Gen 5), 85 NM (100 NM / 120 NM update available via Flow App) |
| Battery Options |
Bosch PowerTube Li-Ion (600 Wh) (dealer upgradeable to 800 Wh, compatible with 250 Wh Range Extender) |
| Display & Remote |
Bosch Mini Remote + System Controller |
| Frame |
7005 hydroformed aluminium, 165 mm F.O.L.D. kinematics, 148x12 mm thru axle, Post Mount 180 mm |
| Frame Special Features |
Geometry adjustment of head angle and chainstay length, Tool bag included (excluding size S), Hidden AirTag or Chipolo holder |
| Fork |
Rock Shox ZEB Ultimate, Debon Air+, Charger 3.1 RC2 w/ ButterCups, 170 mm travel |
| Shock |
Rock Shox Vivid Ultimate Coil, 165 mm travel (Coil rates vary by size: 350/400/500/600 lbs) |
| Brakes (Front | Rear) |
SRAM Maven SVL, 4-piston |
| Disc Brake Rotors |
SRAM HS2, 220 mm (Front) / 220 mm (Rear) |
| Rear Derailleur |
SRAM GX Eagle Transmission AXS, 12-speed |
| Shifter |
SRAM AXS POD Controller |
| Cassette |
SRAM GX Eagle Transmission, 10-52T |
| Chain |
SRAM GX Eagle Transmission |
| Crankset |
SRAM GX Eagle Transmission, 165 mm |
| Chainring |
SRAM Eagle Transmission, 36 T |
| Handlebar |
OneUp Riser, 800 mm width, 35 mm rise |
| Grips |
ODI Elite Pro |
| Stem |
FOCUS C.I.S. 2.0, 40 mm |
| Headset |
ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated angle headset |
| Saddle |
fi'zi:k Ridon X5 |
| Seatpost |
OneUp V3 Dropper (Travel: 150/180/210/210 mm by size), 34.9 mm |
| Wheelset |
DT Swiss HFR 1700, alloy, Mullet (Front: 29" / Rear: 27.5") |
| Tyres (Front | Rear) |
Schwalbe Magic Mary, Super DH, ADDIX Ultra Soft, 29 x 2.4" | 27.5 x 2.4" |
| Weight (600 Wh) |
25.8 kg (in size M, without pedals) |
| Permissible System Weight |
150 kg |
